DJI
DJI Dock 4
A fresh battery in 25 seconds, back in the air in under 45.
- 25-second battery swap
- Up to 80 MB/s offload
- IP56 dock
Pay with
-
Setup & training
included -
12-month
Australian warranty -
Express shipping
Australia-wide
Packages
Ready-made DJI Dock 4 packages
Everything for the job in one box, at the retail price of the DJI or SHARE parts, with the extras added free.
-
DJI Dock 4 Security PackageFree AL2D spotlight$34,400Quote and lead time
-
DJI Dock 4 Survey PackageFree AP1 parachute and 2 TB SSD$34,400Quote and lead time
-
DJI Dock 4 Farm Monitoring PackageFree 12 months of Landmapper$34,400Quote and lead time
-
DJI Dock 4 Bird Scaring PackageFree AS2D speaker and 12 months of Landmapper$34,400Quote and lead time
-
DJI Dock 4 Private Deployment Package10% off the FlightHub 2 All-in-One server$58,799Quote and lead time
Build a Dock 4 package
Dock 4 and the Matrice 5TD Combo with a year of FlightHub 2. Add the AP1 Parachute and DJI Care as the site needs them.
-
01Dock
DJI Dock 4
Battery-swap dock for Matrice 5TD.
$19,360
-
02Aircraft
DJI Matrice 5TD Combo
Wide, medium tele, tele and thermal cameras on one aircraft.
Included O4 Ground Station. Mounted up high, it carries video and control past hills and buildings.
$15,040
-
03Software
1 year includedDJI FlightHub 2
Routes, schedules and live feeds from the office.
-
04DJI Care
< 25 s swap
A fresh battery in 25 seconds
The swap arm lifts out the returning battery and drops in a charged one. Touchdown to the next take-off takes under 45 seconds.
Hands off to the nearest O4 station
O4 roaming lets the aircraft move between ground stations during a flight, extending coverage across a larger site.
Dual SIM
Dual SIM with link fusion
Two nano-SIM slots let the aircraft run two carriers. The O4 link and both 4G links merge into one stream, so a weak connection doesn't drop the video.
Airband radio over IP
Radio over IP brings airband audio to the remote pilot, for flights near other aircraft.
| Battery handling | Battery swap and wireless charging |
|---|---|
| Battery swap time | < 25 s (cover closed to swap complete) |
| Turnaround | < 45 s (landing to take-off) |
| Battery compartment | 4 bays, up to 3 batteries |
| Charging | 2 batteries at once, 15–95% in 27 min at 25 °C |
| Backup power | Compartment batteries, approx. 4.5 h each, up to 3 in sequence |
| IP Rating | IP56 |
| Operating temperature | -40 °C to +50 °C |
| Wind resistance | 12 m/s (max landing wind) |
| Max rainfall | 2 mm/h |
| Max operating altitude | 5,000 m |
| Weight | 66 kg (without batteries or aircraft) |
| Dimensions | Cover open 1750 × 640 × 550 mm · Cover closed 639 × 640 × 836 mm |
| Mounting holes | 400 × 400 mm (same as Dock 3) |
| Input power | 100–240 V AC, 50/60 Hz, max 2,000 W |
| Video transmission | DJI O4 Enterprise Enhanced, via the O4 Ground Station |
| RTK | Via the O4 Ground Station |
| Wi-Fi | Up to 80 MB/s media offload after landing |
| Network | Ethernet via the O4 Ground Station; 4G with DJI Cellular Dongle 2 |
| Operating noise | < 60 dB (Silent mode) · 65 dB (Normal mode) |
Choosing a model
Which aircraft flies from Dock 4?
Matrice 5TD. It carries wide, medium tele, tele and thermal cameras on one aircraft.
What does Dock 4 do that Dock 3 doesn't?
It swaps the battery instead of charging the aircraft in place, so the next flight can launch in under 45 seconds. It also runs down to -40 °C against -30 °C for Dock 3, uses its spare batteries as backup power and takes RTK and transmission from an O4 Ground Station.
On the job
How fast is the battery swap?
25 seconds from the cover closing to a fresh battery in place, and under 45 seconds from touchdown to the next take-off. Up to 2 GB of footage offloads over Wi-Fi during the swap, at up to 80 MB/s.
How many batteries does it hold?
Three charged batteries in a four-bay compartment, with one bay kept free for the battery coming off the aircraft. Standby batteries are held at 95%, and two charge at once, 15 to 95% in 27 minutes at 25 °C.
What happens if mains power drops?
The compartment batteries become the backup supply, about 4.5 hours each, used one after another. With two or more batteries in the compartment, Dock 4 can still swap and launch. Aircraft charging and air conditioning wait until mains power returns.
What weather can it handle?
The dock is rated IP56 and the aircraft IP55, both from -40 °C to 50 °C. It operates in wind up to 12 m/s and rain up to 2 mm/h, at sites up to 5,000 m. The propellers use an anti-icing material.
Buying and delivery
Can we reuse our Dock 3 site?
The concrete base and mounting holes, yes: both docks use a 400 × 400 mm hole pattern. The power cable and RTK don't carry over. Dock 4 uses an LP25 cable, draws up to 2,000 W against 800 W for Dock 3, and takes RTK from the O4 Ground Station.
Does Dock 4 need an O4 Ground Station?
Yes. It carries the dock's video transmission, RTK base station and network link. Dock 4 powers it over PoE through one Ethernet cable, 1.5 to 80 m long, and it mounts high in an open spot with a clear line of sight to the dock.
What does setup involve?
The O4 Ground Station position is surveyed first with a Matrice 4 Series or Matrice 4D aircraft. We then set up the dock and station, calibrate RTK, bind the aircraft, load the batteries and fly the entry and exit route that guides every take-off and return. Training is included.
Data and software
Does it connect to our existing systems?
Yes, through FlightHub 2, run as public cloud, on your own servers or as an all-in-one appliance. OpenAPI and FlightHub Sync link third-party platforms, and DFR workflows push flight requests, live video and evidence into VMS, CAD and SCADA.
What network does the site need?
Ethernet at the O4 Ground Station, ideally gigabit, with more than 20 Mbps up and down (40 Mbps recommended) and latency of 100 ms or less. A DJI Cellular Dongle 2 on the station covers sites without Ethernet, and the aircraft's two 4G links merge with the O4 link.
Can we use Sub-2 GHz in Australia?
Yes. Australia is a supported region. Turn it on in Device Management and accept the liability acknowledgement.
Not sure which kit fits the job?
Tell us the site and the deliverable. We'll name the kit, the price and the lead time.
